Bioreactors fermentors probes media-autoclavs
the answer to a successful cell cultivation.
Welcome on the home page of medorex in Lower Saxony, Germany!
Manufacturer of fully automatic innovative and variable universal bioreactors from 5 ml up to 20 Ltr, from single system up to multiple system with up to 4 units. The multiple software of medorex systems can control the cell-cultivation-process of up to 4 bioreactors with separate control-units and probes by only one computer.
|
medorex stirring systems, 50 ml up to 20 ltr work volume. The systems are equipped with medorex axial stirring system for the cultivation of sensitive cells. They can used in the following sections:
A) medical research.
B) industry laboratories.
C) biotechnology.
D) pharmaceutical and food industry.
|
|
Fixed-bed fermentors, fixedbed-working-volumes from 5 ml up to 6,5 ltr. Total-volumes from 50 ml up to 17 ltr. Systems for a stress-free cultivation of humane, animals and adherent cells. The use fields are as follows:
A) development and production of monoclonal antibodies.
B) the development of medicine and other active agents.
C) research of pollutants elimination.
D) evelopment of different additives and aromatics.
|
|
|
|
|
|
|
|
|
|
FCU 05 controls the rpm of mixer, pH, temperature and the addition of redox to the multiple system with up to 4 fermentors. FCU controls also the gas mixing of cell cultivation under AF or standard conditions.
The system contains the measurement units of probes and connections of further analogous and binary exits. The small Equipment (26 x 16 x 32 cm) finds everywhere a place, to work and to provide exact results.
|
|
A Windows based process-control software on PC with follows features:
- Process visualization.
- Data are shown directly and controlled on the screen.
- All controllers are adjustable by buttons.
- Password protection for several users.
- Data collection & standard, cyclical and long
time saving.
- Remote monitoring and alarm collection.
- Alarms by modem to mobile, telephone, fax
or e-mail.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2-channel pH-, redox-, Ion- rpm and temperature controller. Comfortable for the use in the medical engineering, biotechnology, microbiology, food and other industries.
|
|
Autoclavable pH and DO probes 6 and 12 mm Ø for cell cultivation. Autoclavable temperature probes Pt 100 / Pt 1000, miniaturised, Ø 4 mm, adaptable to all systems.
|
|
A small and comfortable autoclave with 7 Ltr working volume and integrated stirring system for sterilization of cell cultur media under 1 up to 3 bars pressure and up to
143°C.
|
|
Technical information about medorex bioreactors and other products:
www.medorex.com
